FEATURES
HP Zbook Studio G5
15.6" Mobile Workstation
Intel Core i7 i7-8750H
- 16 GB RAM
512 GB SSD
Windows 10 Pro/11
- in-Plane Switching (IPS) Technology
- English (US) Keyboard
- Intel Optane Memory Ready
Processor Manufacturer: Intel
Processor Type: Core i7
Processor generation: 8th Gen
Processor model: i7-8750H
Processor speed: 2.60 GHz
ZBook Studio G5
Thunderbolt 3
Thunderbolt 3 is a hardware interface that utilizes the reversible USB Type-C connector. Doubling the speed of its predecessor, Thunderbolt 3 features a maximum bi-directional throughput of 40 Gb/s when used with compatible devices. The connector also transmits data via USB 3.1 Gen 2 at up to 10 Gb/s, and dual-bandwidth DisplayPort 1.3 allows you to simultaneously connect two 4K displays or one 5K display. Additionally, you can daisy chain up to six devices from a single Thunderbolt 3 port.
DisplayPort 1.3 Protocol Features Supported via Thunderbolt 3
- Legacy displays (HDMI, DVI, and VGA) may be attached to the Thunderbolt port with the use of a certified dongle.
- DisplayPort monitors capable of supporting DisplayPort 1.3 may be directly attached to the Thunderbolt port to achieve HBR2 with the use a dongle.
- Thunderbolt 3-enabled monitors may be directly attached to the Thunderbolt port to achieve HBR2 and MST.
- DisplayPort 1.3 MST (“daisy-chain” feature) is supported through the Thunderbolt 3 port on Thunderbolt 3-enabled devices or DisplayPort 1.3 monitors (requires monitor with DisplayPort 1.3 MST capability) with the use of a dongle.
- Up to two streams (eight lanes) of DisplayPort 1.3 are supported over a single Thunderbolt 3 port. Up to two 4K displays with 24/30-bit color depth at 60 Hz or one 5K display are supported over a single Thunderbolt 3 port. An Intel-certified Thunderbolt cable is required.
- DisplayPort 1.3 w/MST (Multi-stream Transport) supports resolutions up to Full 4K with 24/30-bit color depth at 60 Hz, and WUXGA (1920 x1200) monitors with a 24/30-bit color depth at 120 Hz.
Multi-Display Support with the HP Thunderbolt Dock G2
The HP Thunderbolt Dock G2 has a Thunderbolt 3 port, VGA port, two DisplayPort 1.3 ports, and a USB Type-C port. When used together with the HP ZBook Studio configuration with hybrid graphics, a maximum of five independent displays are supported. These five displays are the internal panel, one external display connected to the system’s HDMI port, and four external displays connected to the ZBook dock’s Thunderbolt 3, VGA, and two DisplayPort ports. When used together with the HP ZBook Studio configuration with Intel integrated graphics, a maximum of three independent displays are supported using any three-display combination of the system panel, system ports, and ZBook Dock ports.
Multi-Display Support without the HP Thunderbolt Dock G2
The HP ZBook Studio with hybrid graphics and without the use of the separately sold ZBook dock supports up to a maximum of three independent displays. These three displays are the internal panel plus two external displays connected to two of the three following ports: HDMI, Thunderbolt 3, and Thunderbolt 3.
The HP ZBook Studio configuration with Intel integrated graphics and without the use of the ZBook dock supports up to a maximum of three independent displays. These three displays are the internal panel plus two external displays connected to two of the three following ports: HDMI, Thunderbolt 3, and Thunderbolt 3
Multi-Display Support Without the ZBook Dock with Thunderbolt 3 (using DP 1.2 MST)
An HP ZBook Studio with hybrid graphics and without the use of the ZBook Dock supports up to a maximum of three independent displays. These three displays are the internal panel plus two external displays connected to two of the three following ports: HDMI 2.0, Thunderbolt 3, and Thunderbolt 3. The HP ZBook Studio configuration with integrated Intel graphics and without the use of the ZBook dock supports up to a maximum of three independent displays using any three-display combination of the system panel plus 2 of the following: HDMI, Thunderbolt 3, or Thunderbolt 3.
Up to 64GB RAM
This ZBook Studio G5 features 16GB of 2666 MHz DDR4 RAM in a 1 x 16GB configuration, which can be upgraded to 64GB by using a 32GB module in each of the two 260-pin SO-DIMM slots.
Additional Internal Storage
There is a second M.2 2280 that is empty and supports PCIe and SATA SSDs.
Wi-Fi 5 (802.11ac)
The system features Intel Dual Band Wireless-AC 9560 which is compatible with 802.11a/b/g/n/ac Wi-Fi so that users may access network connectivity using wireless technology.
Bluetooth 5.0
Additional compatible peripherals, such as mice, keyboards, headsets, and more may be paired using Bluetooth 5.0 technology.
