Model Configuration

PERFORMANCE

Processor
Intel® Core i7-13620H, 10C (6P + 4E) / 16T, P-core 2.4 / 4.9GHz, E-core 1.8 / 3.6GHz, 24MB

Graphics
Integrated Intel® UHD Graphics

Chipset
Intel® SoC Platform

Memory
16GB Soldered LPDDR5x-5200

Memory Slots
Memory soldered to systemboard, no slots, dual-channel

Max Memory
16GB soldered memory, not upgradable

Storage
512GB SSD M.2 2242 PCIe® 4.0x4 NVMe®

Storage Slot
One M.2 2242 PCIe® 4.0 x4 slot

Max Storage Support
One drive, up to 1TB M.2 2242 SSD

Card Reader
microSD Card Reader

Audio Chip
High Definition (HD) Audio, Realtek® ALC3287 codec

Speakers
Stereo speakers, 2W x2, optimized with Dolby Audio™

Microphone
2x, Array

Camera
FHD 1080p with Privacy Shutter

Battery
57Wh

Power Adapter
65W USB-C® (3-pin)

DESIGN

Display
14" WUXGA (1920x1200) OLED 400nits Glossy, 100% DCI-P3, 60Hz, TÜV Low Blue Light, Glass, Touch

Touchscreen
10-point Multi-touch

Screen-to-Body Ratio
89% AAR (active area ratio)

Color Calibration
None

Pen
Lenovo® Digital Pen 2

Keyboard
Backlit, English (UK)

Touchpad
Buttonless Mylar® surface multi-touch touchpad, supports Precision TouchPad (PTP), 75 x 120 mm (2.95 x 4.72 inches)

Dimensions (WxDxH)
313 x 227 x 17.5 mm (12.32 x 8.94 x 0.69 inches)

Weight
Starting at 1.5 kg (3.31 lbs)

Case Color
Luna Grey

Case Material
Aluminium (Top), PC-ABS + 40% GF (Bottom)

Surface Treatment
Aluminium Stamping (Anodized with Sandblasting)

SOFTWARE

Operating System
Windows® 11 Home Single Language, English

Bundled Software
Office Trial

CONNECTIVITY
WLAN + Bluetooth
Wi-Fi® 6, 802.11ax 2x2 + BT5.2

WWAN
Non-WWAN

Ethernet
No Onboard Ethernet

Standard Ports
1x USB-A (USB 5Gbps / USB 3.2 Gen 1)
1x USB-A (USB 5Gbps / USB 3.2 Gen 1), Always On
2x USB-C® (USB 10Gbps / USB 3.2 Gen 2), with USB PD 3.1 and DisplayPort™ 1.4
1x HDMI® 1.4b
1x Headphone / microphone combo jack (3.5mm)
1x microSD card reader

Docking
Various docking solutions are supported via USB-C®.
For more compatible docking solutions, please visit Docking for IdeaPad® 5 2-in-1 14IRH9

SECURITY & PRIVACY

Security Chip
Firmware TPM 2.0

Fingerprint Reader
Touch Style, on Palm Rest

Other Security
Camera privacy shutter

SERVICE

Base Warranty
1-year, Courier or Carry-in

Included Upgrade
2Y Courier/Carry-in upgrade from 1Y Courier/Carry-in

ACCESSORIES

Bundled Accessories
None

CERTIFICATIONS
Green Certifications
ENERGY STAR® 9.0
EPEAT™ Gold Registered
ErP Lot 6/26
RoHS compliant

Mil-Spec Test
MIL-STD-810H military test passed (21 test items)

Other Certifications

Models with OLED panel:
TÜV Rheinland® Low Blue Light (Hardware Solution)

MODEL INFORMATION

Model
83KX003CUE

Machine Type
83KX

Region
MEA

Country/Region
Emat-UK

EAN / UPC / JAN
198154686147

Announce Date
2024-06-28

End of Support
2030-06-27
