TECHNICAL SPECIFICATIONS

Part Number

90NR0LZ6-M00CV0

Color

Platinum White

Operating System

Windows 11 Home

Processor

Intel® Core™ Ultra 9 Processor 285H 2.9 GHz (24MB Cache, up to 5.4 GHz, 16 cores, 16 Threads); Intel® AI Boost NPU up to 13TOPS

Graphics

NVIDIA® GeForce RTX™ 5070 Ti Laptop GPU
ROG Boost: 1565MHz* at 115W (1515MHz Boost Clock+50MHz OC, 95W+20W Dynamic Boost)
12GB GDDR7

Neural Processor

Intel® AI Boost NPU up to 13TOPS

Display

ROG Nebula Display
16-inch 2.5K (2560 x 1600, WQXGA) OLED 16:10 aspect ratio
OLED Glossy display
DCI-P3: 100%
Refresh Rate: 240Hz G-Sync
Pantone Validated
MUX Switch + NVIDIA® Advanced Optimus
Support Dolby Vision HDR : Yes

Memory

32GB LPDDR5X 7467 on board RAM

Storage

1TB PCIe® 4.0 NVMe™ M.2 Performance SSD

Expansion Slots (includes used)
2x M.2 PCIe

I/O Ports
1x 3.5mm Combo Audio Jack
1x HDMI 2.1 FRL
2x USB 3.2 Gen 2 Type-A (data speed up to 10Gbps)
1x USB 3.2 Gen 2 Type-C with support for DisplayPort™ / power delivery / G-SYNC (data speed up to 10Gbps)
1x Thunderbolt™ 4 with support for DisplayPort™ / power delivery (data speed up to 40Gbps)
1x card reader (SD) (UHS-II, 312MB/s)

Keyboard and Touchpad

Backlit Chiclet Keyboard 1-Zone RGB
Touchpad

Camera

1080P FHD IR Camera for Windows Hello

Smart Amp Technology

Dolby Atmos
AI noise-canceling technology
Hi-Res certification (for headphone)
Built-in 3-microphone array
4-speaker (dual-force woofer) system with Smart Amplifier Technology, 2 Tweeters

Network and Communication

Wi-Fi 7(802.11be) (Triple band) 2*2 + Bluetooth® 5.4 Wireless Card (*Bluetooth® version may change with OS version different.)

Battery

90WHrs, 4S1P, 4-cell Li-ion

Power Supply

Rectangle Conn, 200W AC Adapter, Output: 20V DC, 10A, 200W, Input: 100-240V AC, 50/60Hz universal

AURA SYNC

Yes

Device Lighting

Slash Lighting

Weight

1.85 Kg (4.08 lbs)

Dimensions (W x D x H)

35.4 x 24.6 x 1.49 ~ 1.64 cm (13.94" x 9.69" x 0.59" ~ 0.65")

Microsoft Office

1-month trial for new Microsoft 365 customers. Credit card required.

Xbox Game Pass

Xbox Game Pass for PC_3 months (*Terms and exclusions apply. Offer only available in eligible markets for Xbox Game Pass for PC. Eligible markets are determined at activation. Game catalog varies by region, device, and time.)

Security

BIOS Administrator Password and User Password Protection
Trusted Platform Module (Firmware TPM)
McAfee® 1 year
